5 ton QZ Type Travelling Double Girder Overhead Crane System With Waste Grab

Two operating methods, namely, on floor and in the driver's cabin, have been designed for overhead crane with hook cap. The cabin is divided into open-style and closed style. The cabin can be installed on the left or right according to actual conditions The operator can enter the cabin from one side, rear or top, which depends on the different user's requirements.

It is composed with girder frame, crane travel device, and the trolley with lifting and moving device. There is pave the rail for the trolley moves on the main girder.

Assemble the moving table on the outside of the two main girder, one side is prepare for assemble and maintenance the crane move device, another side is prepare for assemble of the trolley conductor device.

There are full field of view cabin suspend under the main girder, there are joint control desk or single control box packed within the cabin, assemble the sidelong ladder between the cabin and moving table.

The main girder joint with the two side end carriage which with the joint point in the middle.

Main Features of QZ model Crane

1. Weight overload protection device.
2. Top quality long time bearing polyurethane materials buffer.
3. Crane travelling limit switch.
4. Voltage lower protection function.
5. Emergency stop system.
6. Current overload protection system and so on!
7. Warning indicator: flashing lights and warning sound
8. Wireless infra-detector for anti-collusion

Product Structure

Attention

Safety is the most important issue for cranes. To ensure the safety,It is prohibited to use the equipment in the combustible, explosive or corrosives environment.(Need explosion proof type for this).Safety system:

1. All the cranes are equipped with overload protection device, Top quality long time bearing polyurethane materials buffer, Crane traveling limit switch, Voltage lower protection function, Emergency stop system and so on.

2. All operations are controlled by central control system. Excellent After Sales Service

3. The whole machines would be guaranteed for one year from the test run date.

4. Low charge for continue maintenance when warranty is expired.

Related Products

NLH double girder European overhead crane

Lifting capacity:5 ~ 50t
Lifting height: Customized
Span: 10.5 ~ 31.5m
Power supply: 220~440V,50/60Hz,3 phase
Working class: A5 ~ A6
Working temperature: -20°c ~ +40°c

Company Information

Certifications

We have passed CE, GOST, SGS, and OHSAS & ISO9001:2000 international quality control,ISO14001:1996 environment and ISO9001:2001 health and safety certifications. We have a perfect quality-control system, a strict management system, and strong production capability and advanced testing measures to ensure the high production and high quality.

Packaging & Shipping

FAQ

1. How can I get a precise crane offer?

A. To providing you a precise crane offer efficiently, please kindly provide details as following:

a). Lifting capacity, material weight(unit as tonnage)

b). Lifting height; (unit as meter)

c). Crane span, the width of inquired crane(unit as meter)

d). Crane traveling length; when rail track/runway beam needed, traveling length shall be provided

e) Working power; power source at site(unit as voltage, phase and Hz)

2. Can I get your crane products with customized personalized service?

A. Yes, Henan Mine Group promise customized personalized products are available for our clients all the time. Just freely let us know your special demands about the products, our engineering team will work on that.

3. What should I do if l'm not able to install the crane after buying?

A. Freely contact us. Our engineering team available for oversea service with crane installation, inspection and commissioning.

Hi, firstly let us introduce our company as follows:

We, Henan Mine Crane Group, have 4,500 employees, include one experienced and professional team for oversea market. We cover an area of 1,620,000 square meters, hold capital of CNY1.18 Billion, have 430 branches around the world and serving over 6,000 Mid-high end customers.

We have more than 200 intermediate and senior engineers who focus on design and manufacture of our cranes, we could supply you all kinds of cranes, more than 110 types. In order to manufacture the best quality crane with high efficiency production, we have invested large number of high technique equipments(include more than 500sets of robots) which can independently accomplish all the processes, such as milling, digging, grinding, pulling, boring, rolling, drilling, punching, cutting, bending, welding, testing and heat treatment. Meanwhile, our factory have passed CE, EAC, SGS, and OHSAS & ISO9001:2000, ISO14001:1996 and ISO9001:2001, have the perfect quality-control system.

In 2020, we have sold 100,000 sets of crane and hoist, sales turnover valued CNY5.675 billion. We haave scored No. 1 on crane sale quantity for continuous 16 years in China local market. We have achieved the remarkable achievements in over 50 key industries such as aerospace, automobile and shipping, steel smelting, petrochemical, electronic information, electric power, water conservancy, railway and military industry. The developed intelligent storage crane, precise positioning crane, automatic container gantry crane, nuclear grade special crane, clean explosion-proof automatic crane, multi fulcrum flexible crane, simulated maritime rescue crane and other high-end products serve Baosteel, China Railway, MCC, CNNC(China National Nuclear Corporation), CASC(China Aerospace Science and Technology Corporation), and other large enterprises; also include oversea project such as Vietnam Yishan Iron and Steel Group, Pakistan Abass Steel Group, Kenya Railway gantry crane projects(Mombasa to Nairobi), Pakistan subway construction bridge cranes project etc, more than 120 countries.

Our Gov have arranged our Group organized and hold many times of International Exhibition Of Crane in China because of our high good influence, meanwhile, our crane have been used on satellite launching because our high technique, and newspaper, local TV, CCTV interviewed and report us many times too.

Quality Forges the Brand, Integrity Waves a bright future. We are trying to win the world with integrity and high quality, We sincerely hope to cooperate with all friends from the world and create brilliance together.

Company Position: The company is the largest industrial crane manufacturer in China, with the highest sales volume and market share in China market.
