    High Technique Remote Control Double Beam Overhead Crane QD Type

    Ask Lasest Price
    Brand Name : KUANGYUAN
    Model Number : QD
    Certification : ISO 9001
    Price : USD 50000-100000/SET
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 SETS/YEAR
    Delivery Time : 60 DAYS
    • Product Details
    • Company Profile

    High Technique Remote Control Double Beam Overhead Crane QD Type

    Product Overview

    Heavy duty A5 double girders overhead traveling crane
    Double girder overhead crane is composed with double girder frame, crane travelling end truck, and the top running trolley with lifting and travelling device. The cranes are equipped with frequency inverter, which makes the crane speeds adjusted under 10 grades speeds. It could move very slow which makes it possible to do very accurate works.
    This model overhead crane is designed under GB regulation, passed ISO, CE certification.
    The crane lifting and travelling speeds are steady and accurate.
    New design also makes the crane lifting higher.
    FEATURES AT A GLANCE
    Main Features of QD model overhead crane:
    1. Heavy duty of M5~M8 (ISO), medium-heavy duty;
    2. Soft start, 3-5 speeds to operate, very stable to lift and running,operation smoothly.
    3. Long life span: 25-30 years;
    4. Six direction action, to make sure the enough wide working area.;
    5. High quality welding work;
    6. Remote control or cabin control;
    7. Electrical parts will be Schneider/Siemens;
    8. Crane is equipped with all moving limit switch, loading limit and other standard safety devices, to promise crane work safe.9.
    Geared motors could be ABM and SEW.
    motors
    limit switch
    hook
    1). Wheels, wire rope drum, gears, couplings are processed by CNC machine center, TOP quality control;
    2). Heavy duty motors with IP54/55, insulation class F
    3). Siemens/Schneider main electric parts are used for durable and safe operation
    4). Frequency inverters could be equipped on the crane for speed controlling.
    More details please contact with us.
    Basic safety device:
    Full safety system as follows:
    Weight overload protection
    Emergency stop system
    Over current protection,Short-circuit protection
    Phase sequence protection
    Zero position protection
    Voltage loss protection
    Limit switch and stopper for crane long traveling and cross traveling
    Lifting overhigh and overlow limit switch (contact with us for more details.)teel
    PRODUCT SPECIFICATIONS
    No
    Item
    Data
    1
    Lifting capacity
    5 - 450 ton
    2
    Lifting height
    1- 40 m
    3
    Span
    10.5- 31.5m
    4
    Working environment temperature
    -40~ 40°C
    5
    Speed
    Hoisting
    Main
    1- 10 m/min
    Aux.
    5-15 m/min
    Trolley
    4- 40 m/min
    Crane
    8- 80 m/min
    6
    Working system
    A5~A8
    Customers visit
    Click it you can find our all customers cases.
