Metallurgy Ladle IP55 40m Double Girder Overhead Crane Working
Class A7~A8
Product Description
Metallurgy Ladle IP55 40m Double Girder Overhead Crane Working
Class A7~A8 is composed of boxed bridge frame, hook, crane travelling mechanism
and electric system. The main hook employs a load tool as the
lifting device to hoist steel ladle, the auxiliary hook cooperate
with the main hook to accomplish pouring of molten steel and steel
slag, and other auxiliary hoisting.Use various speed system with
speed ratio as 1:10 for main mechanisms such as hoisting, trolley
traversing and crane travelling. Also we can choose the suitable
speed under the customer requirement.
Product Structure
| Lifting weight | Primary handcart | T | 100 |
| Secondary handccart | 30 |
| Span | | 16 |
| Lifting height | Primary handcart | M | 18 |
| Secondary handccart | 19 |
| Working class | A7-A8 |
| Speed | Lift | Primary handcart | m/min | 7.54 |
| Secondary handccart | 8.93 |
| Travel | Primary handcart | | 35.08 |
| Secondary handccart | 42.44 |
| Motor | Lift | Primary handcart | Type/kw | YZR355M-10/90×2 |
| Secondary handccart | YZR280M-10/55 |
| Travel | Primary handcart | YZR160L-8/9×2 |
| Secondary handccart | YZR160M1-6/6.3 |
| Cart | YZR225M-8/22×4 |
| Weight | Primary handcart | T | 66 |
| Secondary handcart | 10.25 |
| Cart | 173 |
| Max wheel pressure | KN | 520 |
| Steel track | | QU120 |
| Power supply | | 3-phase A.C. 50Hz 380V
|
Main Features
Working condition:
1. Working tempreture:-10~+60°C,
2. Work class:A6-A8,
3. Power Source:3ph,380V,50HZ or other under customer requirement.
Safety feature:
1. Weight overload protection device,
2. Top quality long time bearing polyurethane materials buffer,
3. Crane traveling limit switch, Voltage lower protection function,
4. Emergency stop system,
5. Current overload protection system and so on!
Product Details
Main Product
Henan Mine Crane meet the demand factory, workshop, port, mining, waste disposal,
goods scattered, petrochemical, aerospace, military and other
industries of universal bridge crane, overhead crane price 20 ton
5ton, eot crane, door crane, universal gantry crane, rubber tyre
and rail mounted container gantry crane, four link type portal
crane, quayside container crane, crane, crane hook, mining grab
crane, gantry crane, ship loader, grab bucket ship unloader,
stacker reclaimer, dredger, mobile platforms and other types of
hydraulic crane.
Certifications
We have passed CE, GOST, SGS, and OHSAS & ISO9001:2000 international quality
control,ISO14001:1996 environment and ISO9001:2001 health and
safety certifications. We have a perfect quality-control system, a strict management
system, and strong production capability and advanced testing
measures to ensure the high production and high quality.
FAQ:
Q1. What do Henan mine crane do ?
A:We design, manufacture, install overhead crane, gantry crane,
port crane, hoists, winch and provide customer lifting solutions.
Q2. Do you provide professional crane servicing ?
A:Yes and our service team offer a range of professional services
to installation and maintain your crane.
Q3. What do I need to consider when purchasing from you ?
A: Standard items to consider when purchasing any lifting equipment
such as overhead crane and gantry crane or hoist, it including safe
working load, span and lifting height, duty cycles and on-going
cost of spare parts.
Q4. What makes you different from other manufacturers ?
A:We have trained service technicians who will be able to get your
material handling equipment up and running, and have been providing
our customers an effective service solution.
Q5. What areas do you service ?
A:We can send engineers provided installations and maintenance in
all over the world.
